泰朗鋼管主要生產不銹鋼無縫鋼管，可生產產品的材質包括奧氏體、雙相鋼、超級雙相鋼和鎳基合金等，具體規格材質請參看下列表格。
| 鋼種 | 主要鋼號 | 規格 |
| 奧氏體不銹鋼 |
TP304,TP304L,TP304H,TP316,TP316H, TP316Ti,TP316L,TP321,TP321H,TP347H, TP347HFG,904L,TP310H,TP310S,TP317, TP317L, TP316LMo≥2.5; etc |
外徑φ6-φ830mm 壁厚0.5-45mm |
| 雙相不銹鋼 | S31803; S32205;S31500; S32750 | 外徑: 10-273mm, 壁厚: 0.5-20mm |
| 鎳基合金 | N08825, N08904, N08028, N08800 | 外徑: 16-273mm 壁厚: 1.65-20mm |
(特殊材質經雙方協商也可生產)
除以上鋼管外，泰朗還可生產以下規格無縫U型管：
| U形管 U-Tube | 外徑φ12-φ38mm, 壁厚0.5-4mm |
熱交換器管 Heat Exchanger
| 主要鋼種/Main Grade | 生產標準/Standard | 規格/Specification |
|
TP304,TP304H,TP316,TP316, TP316L,TP321 |
ASTM A213,ASME SA213, GB13296, JIS3463, DIN17458, EN10216-5 |
OD: 12.7-159mm WT: 0.5-8mm |
鍋爐管 Boiler Tube
| 主要鋼種/Main Grade | 生產標準/Standard | 規格/Specification |
|
TP304H,TP310H,TP316H,TP321H, |
GB5310,GB13296,ASTM A213, ASME SA213,EN10216-5, |
OD: 33.40-273.0mm WT: 2.11-20.0mm |
船用管 Marine Tube/Pipe
| 主要鋼種/ Main Grade | 生產標準/Standard | 規格/Specification | 船級社認證 |
|
TP304H,TP304L,TP347H, TP321, TP321H,316高鉬 |
GB14976, ASTM A312, A269, JIS G3459 |
OD: 6.0-273mm WT: 0.5-16.0mm |
ABS,BV,CCS, DNV,GL,LR,KR |
儀表管Instrumentation Tube
| 主要鋼種/Main Grade | 生產標準/Standard | 規格/Specification |
|
TP304,TP304L,TP316, TP316L,TP317L,TP321, |
GB/T14976,EN10216-5, |
OD: 6-76.0mm WT: 0.5-6.0mm |
通用管 General Tubes & Pipes
| 主要鋼種/Main Grade | 生產標準/Standard | 規格/Specification |
|
TP304,TP304L,TP304H, TP316,TP316H,TP316Ti, TP316L,TP321,TP316Mo |
GB/T14976,EN10216-5, DIN17456,DIN17458,ASTM A312,JISG3459 |
OD: 10.0-830.0mm WT: 1.65-45.0mm |
雙相不銹鋼 Duplex Tubes/Pipes
| 主要鋼種/Main Grade | 生產標準/Standard | 規格/Specification |
| S31803; S32205;S31500; S32750 | ASTM A789 |
OD: 12.0-219.0mm WT: 0.5-14mm |
| ASTM A790 |
OD: 10.0-273.0mm WT: 0.5-20mm |
鎳基合金
| 主要鋼種/Main Grade | 生產標準/Standard | 規格/Specification |
|
N08825,N08904, N08028,N08800 |
ASME SB 163, ASTM B 163, ASME SB423, ASTM B423, ASME SB407, ASTM B407, ASME SB668, ASTM B668 |
OD: 16-273mm WT: 1.65-20.0mm |
